Szepter Core 4

We cut no corners for the highest CORE level – these uncompromising team level packages are made to take on the most demanding terrain. The SZEPTER CORE 4 features only the best components and oozes performance from every detail. Tunable and compliant, the suspension elements deliver a degree of freedom never seen with a gravel bike, offering a capable platform when the terrain gets rowdy. From far-reaching singletrack to your home trails, this CORE 4 edition leaves nothing to be desired. So, no more excuses!



Specifications

Frame

Frame Size S, M, L, XL, XXL
Color MACHINE LIGHT GREY

Wheels

Wheels WTB PROTERRA LIGHT I23 Front: 700c I 100 x 12 mm I 6 bolt I Stainless Steel bearings I TCS Rear: 700c I 142 x 12 mm I 6 bolt I Stainless Steel bearings I Ultra Quick Engagement 3.7° I TCS I XDR
Tires WTB RESOLUTE 700c x 42c I TCS Light / Fast Rolling I 60 tpi I DUAL DNA

Suspension

Fork ROCKSHOX RUDY ULTIMATE XPLR 700c | 40 mm | Solo Air I Rebound adj. | Charger Race Day damper | Lockout | Glossy Black I 12 mm x 100 mm | 51 mm Offset

Drivetrain

Crankset SRAM FORCE 1 WIDE 170 mm (S) 172.5 mm (M - L) 175 mm (XL - XXL) | 38T I DUB
Cassette SRAM XG1271 XPLR 10-44T | 12-Speed
Rear derailleur SRAM FORCE XPLR ETAP AXS 12-Speed | AXS Battery
Shiftbrake SRAM FORCE ETAP AXS HRD Rotor SRAM HS2 front 180 mm / rear 160 mm Left | Right
Bottom Bracket SRAM DUB PRESSFIT BB DUB PF 86.5 Road Wide

Components

Headset ACROS AIA-538 IS52/52 I High Cap I 2 Spacer 5mm
Stem ZIPP SERVICE COURSE SL 70mm | 31.8 mm I +/-6° | Titanium Hardware | Black
Handlebar ZIPP SERVICE COURSE XPLR 420 mm (S) 440 mm (M-L) 460 mm (XL-XXL) I 31.8 mm I 70 mm Reach | 115 mm Drop | 11° Outsweep | 3° Backsweep | 5° Flare
Seatpost SRAM REVERB AXS XPLR Ø 27.2 mm | 50 mm (S-L) I 75mm (XL-XXL), with ActiveRide™
Saddle SDG BEL-AIR V3 OVERLAND YT Custom Design | Lux-Alloy Rail | Width 140mm
Bar Tape FIZIK TERRA BONDCUSH Tacky | 3 mm | Black

Weight

Weight 9.90 KG / 21.82 LBS Average weight for the smallest size available, set up tubeless, with no pedals or bottle.
